Stm28 series integrated servo motor CANopen Integrated Brushless Servo Motor

Nema11 closed loop stepper motor is an integrated small servo system, which only increases 1.5cm on the basis of nema11 standard motor shape. Optional CANopen (ds402) and Modbus communication control. Closed loop control mode is adopted to prevent out of step

Features

  • Integrated and concise design
  • Nema11 size
  • CANopen or Modbus Control
  • Closed loop servo
  • Stable operation, low heating
  • 10000 count / cycle encoder

Specifications

Size(mm):Nema11(28) mm
Rated Speed (RPM):1000rpm
Torque (Nm):0.09-0.12 Nm
Interface:Canopen Modbus RTU
OEM Programmable:No
Inputs & Outputs:

3 digital inputs and 2 digital outputs

Optional Gearbox:Yes
IP Protection:IP54
Customization:R out shaft D flat shaft K keyway
